KAYDON KB020XP0 thin section bearing
| Part Number | KB020XP0 |
| System of Measurement | Inch |
| Bearing Type | Ball |
| For Load Direction | Four Point Contact |
| Construction | Single Row |
| Seal Type | Open |
| Series | KB 5/16" x 5/16" |
| Bore Dia | 2" |
| Bore Dia Tolerance | -0.0006"- 0" |
| Outer Dia | 2.625" |
| Outer Dia Tolerance | -0.0005"- 0" |
| Width | 0.3125" |
| Width Tolerance | +.000 –.005" |
| Land dia.L1 | 2.231" |
| Land dia.L2 | 2.393" |
| Ring Material | 52100 Chrome Steel |
| Ball Material | 52100 Chrome Steel |
| Cage Material | Brass |
| Dynamic Radial Load | 758 lbs |
| Dynamic Thrust | 1130 lbs |
| Dynamic Moment | 658 lbs |
| Static Radial Load | 930 lbs |
| Static Thrust | 2340 lbs |
| Static Moment | 1080 lbs |
| Lubrication | Lubricated |
| Shaft Mount Type | Press Fit |
| Temperature Range | -30°C to 110 °C |
| ABEC Rating | ABEC-1 |
| Radial Clearance | 0.0000 – 0.0005" |
| RoHS | Compliant |
| Weight | 0.16 lbs |
