Spherical roller bearing

HEPHAIST SRJ004C SRJ006C SRJ008C SRJ012C SRJ016C SRJ024C SRJ032C SRJ048C Spherical Rolling Joint HEPHAIST SRJ004C SRJ006C SRJ008C SRJ012C SRJ016C SRJ024C SRJ032C SRJ048C Spherical Rolling Joint HEPHAIST SRJ004C SRJ006C SRJ008C SRJ012C SRJ016C SRJ024C SRJ032C SRJ048C Spherical Rolling Joint HEPHAIST SRJ004C SRJ006C SRJ008C SRJ012C SRJ016C SRJ024C SRJ032C SRJ048C Spherical Rolling Joint

HEPHAIST SRJ004C SRJ006C SRJ008C SRJ012C SRJ016C SRJ024C SRJ032C SRJ048C Spherical Rolling Joint

HEPHAIST   SRJ004C SRJ006C SRJ008C SRJ012C SRJ016C SRJ024C SRJ032C SRJ048C  Spherical Rolling Joint

Cylindrical direct drive bearings, systems, and mechanical products are with high accuracy and precision.


Up until now, the joints requiring multiple degrees of freedom that are indispensable for parallel mechanisms have achieved two or three degrees of freedom by combining rotational joints.

There are also sliding spherical bearings with multiple degrees of freedom, but they have had large friction resistance and internal clearances.

To solve these problems, HEPHAIST developed a spherical bearing with a rolling mechanism.

High Rigidity and High Precision with Zero Clearance Rolling Guideways


The essential multi-degree-of-freedom joints for parallel mechanisms have conventionally been obtained 2 to 3 degrees of freedom with combinations of spherical joints. However, such spherical joints combinations often lead to structural complexity and bulkiness.
There are multi-degree-of-freedom sliding spherical ball bearings available, but they come with large frictional resistance and internal clearance issues.
Hephaist has developed SRJ - Spherical Rolling Joints as the solutions to all these issues.
