INA GE60 DO-2RS Geg60es Radial Spherical Plain Bearings
Main specifications
- Availability124 pcs
- BrandINA
- Item NumberGE60-DO-2RS INA
- Also known as0066482230000
GE60ES-2RS - EAN4012802568004
- CategorySpherical Plain Bearing
Weight and Dimensions
- Inner (d) MM60
- Outer (D) MM90
- Width (B) MM44
- Weight (kg)0.99
Product Properties
- Seal2RS - Rubber Seal on Two Sides
- Contact MaterialSteel on Steel
Data from Schaeffler (medias)
- Radial Static Load Rating C0r (N)1220000
- Radial Dynamic Load Rating Cr (N)245000
- ECLASS number23-05-01-06
- ECLASS2 number23-05-01-06
- Medias descriptionRadial spherical plain bearing, requiring maintenance, sliding contact surface: steel/steel, DIN ISO 12240-1, dimension series E, sealed
Suffix description
- DOSliding Contact Surface Steel/Steel & Inner And Outer Ring Hardened
- 2RSLip Seals On Both Sides
- E55N
