browning bearing VER-223 VER212 VER225 VER 217

765284 Ball Insert Bearings - Round Bore, 1.4380 in ID, Standard Duty, 2.8350 in OD, 1.6880 in Width, Setscrew Locking

SPECIFICATIONS
Bore Type    Straight
Bore Diameter    1.4380 in
Duty Type    Standard Duty
Internal Clearance    Standard
Outside Diameter    2.8350 in
Outer Ring Width    0.9380 in
Maximum Operating Temperature    200 °F
Inner Ring Width    1.6880 in
Overall Width    1.6880 in
Locking Device    Setscrew
Operating Temperature Range    -20 to 200 F
Fillet Radius    0.0400 in
Radial Dynamic Load Capacity    5782 lb
Radial Static Load Capacity    3493 lb
Bearing Material    52100 Bearing Steel, Black Oxided Inner
Cage Material    Plastic
Snap Ring Included    With Snap Ring
Finish/Coating    Black Oxide Coated Inner Ring
Maximum RPM    4000 rpm
Retainer Material    Molded fiber glass reinforced nylon
Retainer Type    Ball Riding Retainer
Seal Type    Single Lip Contact Seal
Expansion Type    Non-Expansion Bearing (Fixed)
Series    VER 200
Precision Rating    ABEC 1
Misalignment Angle    None
Housing Type    Insert Only
Lubricant    Lithium Complex NLGI 2 Grease
Dynamic Load Capacity    5782 lbs
Lubrication    Lithium Complex NLGI 2 Grease
CAD Drawing    Click here
Manufacturer Catalog Number    VER-223
Manufacturer Product Page    Click here
Manufacturer Catalog    Click here
Manufacturer UPC Number    662289859696
Weight    1.14 lbs
Bore Diameter    1.4380 in
Outside Diameter    2.8350 in
